Icon Platform Nano Air ICO-PLATFORMNANOAIR

Wireless MIDI/audio control surface with motorized fader for production

The Platform Nano Air is a MIDI control surface for producers, engineers, musicians and home studio enthusiasts who want hands on control of their modern “in the box” digital music production with a small footprint. The Platform Nano DAW Controller, adds tactile control with a single motorized fader via USB 3.0 or Bluetooth wireless to your Digital Audio Workstation (DAW) and production system. With one (1) full sized motorized fader, four (4) rotary dual-function encoder knobs, backlit buttons for Mute, Solo, Automation and Transport control, a jog wheel, and access to your entire mix by banking across tracks in groups of 8 or 1 channel at a time

Mackie Control and HUI protocols provide seamless integration with most popular Digital Audio Workstations. Overlays for Cubase, Nuendo, Ableton Live, ProTools, Logic, Reason, Studio One, Bitwig, FL Studio, Adobe Audition, Digital Performer, Sonar, Samplitude and Reaper come standard with your controller. Bitwig Studio 8-Track is included.

For optimal track and parameter monitoring, we recommend you use Platform Nano with the optional Platform D3 display.

2.4G (Generation 4.0) wireless module built-in

1 touch-sensitive motorized fader with 10-bit resolution

Extremely compact, durable and versatile

Customize the perfect setup with a variety of Platform extension modules

Backlit LCD to display channel name, control values etc. for each channel

1 + 4 dual-function encoder knobs (Rotate and enter)

11-segment LED surrounding the encoders to indicate the rotating position for the main knob control

12-segment LED display showing time or location of your project in either SMPTE or Midi beat clock (bars, beats, ticks) format

Jog wheel shuttle for fast search, scrub and control

8 color-coded function buttons coordinate with

5 different color layers for switching a variety of function controls

Illuminated buttons for channel control including Mute, Solo and Record

6 illuminated transport buttons including Play, Stop, Rec, Rewind, Fast Forward and Loop

Illuminated “Zoom” buttons with 2 directional keys (Left/Right & Up/Down) used in combination with the jog wheel

2 illuminated “Track” buttons for easy selection of individual channels

2 illuminated “Bank” buttons for shifting

8-channels at a time

Supports Universal Mackie Control and HUI protocols for seamless integration with most compatible music production software

The most popular DAW overlays are included – Cubase/Nuendo, Logic Pro X, Digital Performer, FL Studio, Samplitude, Reaper, Studio One, Bitwig, Reason, ProTools, Sonar, Audition, Ableton Live and User Define Mode

Bitwig Studio 8-Track DAW is included.

iMapTM software included for easy mapping of MIDI functions

USB 3.0 high speed connectivity

Firmware upgrade available via USB connection and iMapTM software

BlueTooth wireless connectivity and rechargeable battery

User A & User B 1/4 inch connectors for connecting with footswitch pedals

3000mAh Li-ion polymer rechargeable battery built-in for up to 5-6 hours continues operation

Platform D3 OLED display (Optional) connector available

Class-compliant with Mac OS X, Windows 10, Windows 8 (32-bit & 64-bit), Windows 7 (32-bit & 64-bit)

Superior build quality and robust metal casing with Kensington lock port

Bitwig 8Track included

Dotec audio plugins included
